6ft South Africa 2-pin to C7 Power Cord with H03VVH2-F 0.75mm

SKU #P-ZIP-06B-SA
South Africa to C7 power cord: BS546 standard South Africa and India plug to IEC C7 with H03VVH2-F 0.75mm_ wire black power cord; 6 feet with SABS and BIS approvals.
- +

In stock

Ships Today If Ordered By 1pm PST

Purchasing this item will earn you 2 reward points (Reward point(s) $0.06) ! Applies only to registered customers, may vary when logged in.

Description

South Africa to C7 power cord: BS546 standard South Africa and India plug to IEC C7 with H03VVH2-F 0.75mm wire black power cord, 6 feet with SABS and BIS approvals.

Specifications
Male Plug South Africa SABS 164-3, also known as India IS1293 and British standard BS546 (molded with 50P PVC)
Female Receptacle IEC60320 C7 (molded with 50P PVC)
Wire Jacket Standard H03VVH2-F
Gauge 0.75mm
Conductors 2 Wire
copper wire stranding 24 strands of 0.202 x 0.01mm
Jacket Material PVC
Temperature Rating Up to 70C
Wire Outer Diameter 3.4 x 0.1mm by 5.6 x 0.15mm (Two dimensions because this is not round wire)
Conductor Color Code Blue, Brown; ECC (European color code)
Voltage Up to 250 Volts AC
Amperage Up to 2.5 Amps
Cord Length 6 Feet
Color Black
Number per carton 100
Carton Weight 28 lbs (12.4kg)
Carton Dimensions 40 X 30 X 23cm (15.75 X 11.8 X 9 inches)
Testing 100% are individually tested for Hi-Pot (dielectric voltage withstand test), opens, shorts and pinout.
Certifications South Africa SABS and the India BIS/STQC certification renewal is pending
Environmental Compliance RoHS, REACH, Sony Green Partner, ISO14001:2004, ISO9001:2008
Country of Origin China

Technical Drawings

Technical Drawings

Warranty

Lifetime
