8 Port 10/100M Unmanaged Switch SF1008D
In stock
Purchasing this item will earn you 2 reward points (Reward point(s) $0.06) ! Applies only to registered customers, may vary when logged in.
Description
TP-Link product page:SF1008D
The SF1008D 8-port 10/100Mbps Fast Ethernet Switch provides 8 10/100Mbps Auto-Negotiation RJ45 ports. All ports support Auto MDI/MDIX function, eliminating the need for crossover cables or Uplink ports. The Switch is Plug-and-Play and each port can be used as general ports or Uplink ports and can be simply plugged into a server, a hub or a switch, using straight cable or crossover cable.
The SF1008D 8-port 10/100M Fast Ethernet Switch provides you with a low-cost, easy-to-use, high-performance, seamless and standard upgrade to improve your old network to a 100Mbps network. It will boost your network performance up to full duplex data transfer. Its wire-speed switching that forwards packets can be as fast as the speed that your network delivers those packets to them.
- Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for half-duplex mode
- Supports MAC address auto-learning and auto-aging
- LED indicators for monitoring power, link, activity
- Plastic case, desktop or wall-mounting design
- External Power Adapter supply
Standards and Protocols |
IEEE802.3, 802.3u, 802.3x, CSMA/CD, TCP/IP |
Basic Function |
Wire-speed Performance |
MAC Address Auto-Learning and Auto-aging |
|
IEEE802.3x flow control for Full-Duplex Mode and backpressure for Half-Duplex Mode |
|
Backbound Bandwidth |
1.6Gbps |
MAC Address Table |
1k |
Forwarding Rate |
10BASE-T: 14880pps/port
100BASE-TX: 148800pps/port |
Transmission Method |
Store-and-Forward |
Ports |
8 10/100Mbps Auto-Negotiation RJ45 ports (Auto
MDI/MDIX) |
Network Media |
EIA/TIA-568 100 ohm STP (maximum 100m)
100Base-Tx: UTP Cat.5E cable (maximum 100m)
EIA/TIA-568 100 ohm STP (maximum 100m) |
LED Indicators |
Power, Link/Act (1, 2, 3, 4, 5) |
Safety & Emission |
FCC, CE |
Dimensions (W*D*H) |
5.5 x 3.4 x 1.1 in. (140 x 87 x 27.5 mm) |
Environment |
Operating Temperature: 0C~40C (32F~104F) Storage Temperature: -40C~70C (-40F~158F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
Power |
External Power Adapter |
