hdmi 2.0 vs hdmi 2.1

Technology is improving constantly, which is why HDMI standards are vital, especially when the intention is to enhance gaming, home theatre, or workstations.

HDMI, the High-Definition Multimedia Interface, has, over time, become associated with connecting devices to screens.

Recently, HDMI 2.1 brought a new challenge regarding how it differs from the previous formulation, the HDMI 2.

It won’t be a bad idea to go through the two subtypes to be in a position to select the right one that fits a particular need. Who cares, you ask? Well anyone who fires up their gaming PC for high-frame-rate gaming, watches 4K movies, or sets up a new workspace. But you can be affected by choosing HDMI 2.0 or HDMI 2.1.

In this blog, we find out what distinguishes HDMI 2.0 from HDMI 2.1 and which setup is better for a particular home.

What is HDMI?

hdmi cables

HDMI is an interface that connects devices like television sets, monitors, and gaming systems, and it supports both voice and pictures in high definition.

It was said to have been invented to do away with other cables, such as the VGA and DVI cables, since they offer both sound and picture.

HDMI has undergone various improvements over the years to embrace higher resolutions, fast refresh rates, and other qualities.

The need for better picture quality, for instance, 4K and 8K, and better performance in gaming and streaming is at the core of this evolution. New HDMI versions also offer better integration with some devices, such as soundbars and home theater systems.

What is HDMI 2.0?

HDMI 2.0 is that version of HDMI—High-Definition Multimedia Interface – standard launched in 2013.

The format supports increasing video and audio quality compared to previous versions. HDMI 2.0 can support 4K to 60 frames per second compressional video.

It also provides higher bandwidth; data transfer is 18 Gbps. This is good news for the public because it means high-quality video streams and less frame skipping for game lovers. HDMI 2.0 is quite popular in TVs, monitors and gaming consoles.

Key Features of HDMI 2.0

  • 4K@60Hz: It supports only higher resolution standard video modes such as 4K at 60 frames per second.

  • 18 Gbps Bandwidth: Raises maximum data transfer rate to 18 Gbps.

  • 32 Audio Channels: Hammers up to 32 audio channels ideal for the audio results.

  • Dual Video Streams: Enables two video streams on one screen simultaneously.

  • Dynamic Auto Lip-Sync: Ensures that the start and end times of documents, clips, captions, audio descriptions, and other components match with the video.

  • BT.2020 Color Space: Supports BT. 2020 color gamut to increase the resolution of displayed videos.

  • HDR (High Dynamic Range): HDR content is supported to achieve improved contrast and a wider range of colors.

  • Up to 1536 kHz Audio: High-quality audio support with sampling frequencies of up to one and a half megahertz.

  • CEC Extensions: Increased CEC at improved efficiency utilizing a greater percentage of time compared to previous systems.

  • 4:4:4 Chroma Subsampling: Fully supports it to provide a detailed representation of colors in the video.

What is HDMI 2.1?

HDMI 2.1 is an edition of the HDMI standard formulated in 2017. It enables quicker connectivity between devices and more video referrals, like 4K at 120Hz and 8K at 60Hz. This makes it ideal for gaming, high-quality video, or anything that demands high-end graphics.

It also supports dynamic HDR, enhancing color and contrast on the spot. Other capability includes eARC, the enhanced Audio Return Channel, which is mainly important for home theater systems.

The newer version of HDMI, version 2.1, can work with the older HDMI connections but provides the best results with the newer connections.

Key Features of HDMI 2.1

  • Higher Bandwidth: Offers up to 48Gbps for more data transfer capabilities.

  • 8K Resolution: Compatible with 8K @ 60Hz and 4K @ 120 Hz.

  • Dynamic HDR: Enables the alteration of HDR metadata between frames flexibly.

  • eARC (Enhanced Audio Return Channel): Supports premium audio like Dolby Atmos and DTS audio.

  • Variable Refresh Rate (VRR): Helps minimize lag and tear that harms the image on the screen during gaming.

  • Auto Low Latency Mode (ALLM): Adaptively changes to a low latency profile for a game without the need to manually toggling it.

  • Quick Frame Transport (QFT): Reduce lag time for the video with less blur.

  • Quick Media Switching (QMS): Erases the problem of delay time when switching between video modes.

  • Enhanced CEC (Consumer Electronics Control): Enhances coordination of interoperability of devices and control over them.

  • Backward Compatibility: Works with older HDMI versions and older but without high-speed options.

HDMI 2.0 vs. HDMI 2.1: The Key Differences



Feature HDMI 2.0 HDMI 2.1
Max Bandwidth 18 Gbps 48 Gbps
Max Resolution 4K @ 60Hz 10K @ 120Hz
Max Frame Rate 4K @ 60Hz 4K @ 120Hz, 8K @ 60Hz, up to 10K
Dynamic HDR Not supported Supported (HDR10+, Dolby Vision, etc.)
Variable Refresh Rate (VRR) Not supported Supported (reduces screen tearing in gaming)
Auto Low Latency Mode (ALLM) Not supported Supported (automatically switches to low-latency mode for gaming)
eARC (Enhanced Audio Return Channel) Not supported Supported (better audio quality, supports advanced formats like Dolby Atmos)
Quick Frame Transport (QFT) Not supported Supported (reduces lag for smoother gameplay)
Quick Media Switching (QMS) Not supported Supported (eliminates the delay when switching between video modes)
Max Color Depth 10-bit (4:2:0 subsampling) 12-bit (4:4:4 subsampling)
Compression Support No compression (uncompressed only) Display Stream Compression (DSC) supported
Cable Compatibility Standard HDMI cables Requires Ultra High-Speed HDMI cable for full features
Audio Return Channel (ARC) Supported Enhanced to eARC in HDMI 2.1



HDMI 2.0 vs HDMI 2.1: Which HDMI Version Do You Need?

1. Bandwidth and Resolution

Whether to select HDMI 2.0 or HDMI 2.1 depends on what the user needs in order to purchase.

The HDMI 2.0 gives a bandwidth of 18Gpbs which is suitable for 4k for 60Hz. This is fine for normal 4K Televisions and most home theater systems. That’s why the HDMI 2.1 with a nominal bandwidth of 48 Gbps is such a leap forward.

It sustains higher resolutions up to 10K and 4K at the rate of 120Hz. This is perfect for gamers or anyone who wants to invest in future technology for better picture display.

2. Refresh Rates

The answer to which HDMI version to choose involves the resolution and refresh rate. HDMI 2.0 also supports a format of 4K at a frequency of 60Hz, which is fine for watching movies.

They also invited 1080p at 120Hz, which is suitable for Full HD gaming on fast-paced games. Nevertheless, if you desire greater frame rates than the 4K range, HDMI 2.1 is the most appropriate.

It supports up to 4K at 120Hz, which gamers would find useful because action becomes smoother at high resolution. HDMI 2.1 is also capable of supporting 8K @ 60Hz, so your system is ready for the upgraded resolution in the future.

3. Dynamic HDR

HDMI 2.0 is okay for general HDR handling if you don’t require cutting-edge HDR formats. It supports static HDR formats such as HDR10.

Static HDR refers to the fact that the color and the contrast are set to a constant value throughout the entire video.

Nonetheless, HDMI 2.1 is preferable if you want a more advanced picture. It also includes new dynamic HDR formats such as Dolby Vision and HDR10+.

Dynamic HDR allows the colors and contrast to be shifted to match the scene, enhancing the image quality.

4. Variable Refresh Rate (VRR)

If you are to decide which HDMI version is suitable for gaming, then HDMI 2.1 is preferable because of VRR support.

VRR helps combat lag, stuttering, and screen tearing while playing a game. This is crucial for action games where graphics differences and aiming ideally are substantial.

Another shortcoming of HDMI 2.0 is the lack of VRR, which means the game’s quality may be worse.

If VRR is not enabled, you might experience more graphics-related problems, such as fluctuating frame rates. Therefore, if you want smoother gaming performance, go for HDMI 2.1.

5. eARC (Enhanced Audio Return Channel)

For normal sound requirements involving a soundbar or receiver, the HDMI 2.0 with ARC is enough.

ARC works with standard audio codecs, which should be sufficient for most configurations. However, if you desire the best sound quality, such as Dolby Atmos or DTS, then you need HDMI 2.1 with eARC because it has the capacity to carry much higher audio bandwidth.

This is especially so for homeowners who have invested in a home theater or quality speakers. So, all in all, if you want immersive sound, you should get HDMI 2.1.

Conclusion

In conclusion, HDMI 2.1 can be considered an enhancement to HDMI 2.0 with expanded features, particularly regarding the higher refresh rates, better resolution support, and VRR for gamers.

HDMI 2.1 is indeed worthwhile for those who play games on next-gen consoles or are planning to upgrade to an 8K display.

Standard streamers or movie lovers can enjoy high-quality 4K at 60Hz using HDMI 2.0.

Reflect on your current device use and what you will require in the future. Upgrading is not always essential, and you need to know that there are cases where your setup requires it.

Before deciding between the two, consider your current equipment to make sure it aligns with your long-term intentions for using the technology.
